Specification Category |
Feature |
Technical Detail |
|
General |
Brand |
Anchor (by Panasonic) |
|
|
Product Type |
Miniature Circuit Breaker (MCB) |
|
|
Item Code |
98030 |
|
|
Series |
UNO (Inferred) |
|
Electrical |
Current Rating |
32 Amps |
|
|
Number Of Poles |
3 (Three Pole - TP) |
|
|
Circuit Breaker Type |
Standard ('C' Curve Inferred) |
|
Physical |
Mounting Type |
Screw Mount |
|
|
Weight |
320 g |
|
|
Dimensions (LxWxH) |
44.5 x 40.8 x 24.0 CM |
|
Tripping Mechanism |
Thermal and Magnetic |
|
|
Voltage |
415V AC (Inferred Standard) |
|
|
Breaking Capacity |
10 kA (Inferred Standard) |
|
|
Installation |
Panel/Enclosure Mount |
|
Medium Current Rating: Rated for 32 Amps, providing essential overcurrent protection for moderately loaded three-phase circuits, commonly used for smaller motors or sub-distribution boards.
Three Pole (TP) Configuration: Features 3 Poles, allowing for the simultaneous isolation and protection of all three live lines in a three-phase system (Neutral not switched).
'C' Curve Protection: Built with the Standard Circuit Breaker Type and 'C' Curve tripping characteristic, ideal for protecting general loads and ensuring reliable thermal and magnetic tripping.
Screw Mount Design: Specified with Screw Mount compatibility, allowing for a permanent, secure, and fixed installation within an electrical panel or enclosure.
UNO Series Quality: Manufactured by Anchor (by Panasonic) under the reliable UNO Series, ensuring quality construction and long operational life for critical power protection.
