Specification Category |
Feature |
Technical Detail |
|
General |
SAP No / Ref No |
140010669 / EDE-CZ20-2A4 |
|
|
Range Name |
PROFESSIONAL TOOLS |
|
|
Colour / Material |
RED / Not Specified (Plastic+Metal Inferred) |
|
Electrical |
Rated Voltage |
20V |
|
|
Battery |
4.0Ah x 1 (Lithium-Ion) |
|
|
Motor Type |
Brushless Motor |
|
Performance |
Max Torque |
50 N.m (Spec list) / Up to 70 N.m (Sales Point) |
|
|
Torque Settings |
20 + 1 + 1 (Drill, Drive, Impact) |
|
|
No-load Speed |
0-450 / 0-1800 rpm |
|
|
Impact Frequency |
0-7650 / 30,600 bpm |
|
Capacity |
Chuck Capacity |
Φ10mm |
|
Logistics |
Product N.W (Unit) |
3.97 KG |
|
|
Package |
BMC (Blow Molded Case) |
|
Technology |
Deli TPM Heat Management System |
|
|
Protection |
Overload and Overheat Protection |
|
|
LED Light |
Integrated LED Worklight |
|
|
Grip |
Ergonomic Rubber Overmold |
|
High-Performance Brushless Motor: Features a Brushless Motor with a 2nd high-density motor design and a fine-tuned transmission system, delivering strong power and a max specified torque of 50 N.m.
Excellent Endurance and Life: Equipped with a 4.0Ah large-capacity battery pack and integrated with Deli TPM (Thermal Protection Management) heat management system for longer endurance and extended battery life.
Intelligent Safety and Quality: Utilizes a Large computing power chip and 8 kinds of intelligent security algorithms for Deli quality whole process monitoring, ensuring safe and reliable operation.
Versatile Drilling Modes: Offers 20+1+1 Torque Settings (Drill, Drive, Impact) with a massive Impact Frequency up to 30,600 bpm for efficient drilling in masonry, and a high no-load speed up to 1800 rpm.
Professional Speed and Chuck: Features a dual-speed gearbox (0-450/0-1800 rpm) and a reliable Φ10mm Chuck Capacity, packaged in a durable BMC (Blow Molded Case) for transport and protection.
