Specification Category |
Feature |
Technical Detail |
|
General |
Ref No / SAP No |
EDL-XQ355-E1 / 100157876 |
|
|
Colour |
YELLOW |
|
|
Material |
Plastic + Iron |
|
|
HS Code |
8464109000 |
|
Electrical |
Rated Power |
2300W |
|
|
Rated Voltage |
220-240V~50/60Hz |
|
Performance |
No-load Speed |
3900 rpm |
|
|
Disc Diameter |
355mm (14") |
|
Max. Capacity |
Round Pipe |
100 mm |
|
|
Square Steel |
100 x 100 mm |
|
|
Rectangle |
120 x 100 mm |
|
|
Steel Bar |
30 mm |
|
Logistics |
Product G.W (Unit) |
14.13 KG |
|
|
Master Quantity |
1 CAR |
|
|
CBM (m³) |
0.076 |
|
Blade Arbor Size |
Typically 25.4 mm (1 inch) |
|
|
Included Blade Type |
Abrasive Cut-Off Blade |
|
|
Cutting Method |
Dry Cut |
|
|
Cutting Angle |
Fixed 90° / Quick Adjustable Vise |
|
Extreme Cutting Power: Features a high-power 2300W motor with high-overload capacity, designed to respond reliably to various high-intensity and heavy-duty metal cutting applications.
Large Cutting Capacity: Equipped with a 355mm (14-inch) Disc Diameter and a 3900 RPM No-load speed, capable of maximum cutting capacity on materials up to:
Round Pipe: 100 mm diameter
Square Steel: 100 mm x 100 mm
Rectangle: 120 mm x 100 mm
Steel Bar: 30 mm diameter
Enhanced Durability and Stability: Built with a Reinforced chassis which significantly enhances support for the cut material while effectively reducing vibration during the cutting process.
User-Friendly Maintenance: Designed with an External replaceable carbon brush, allowing for convenient, fast, and easy maintenance to extend the motor's lifespan.
Safety and Convenience: Includes a Safety latch and fasten latch button to ensure secure operation and easy handling when transporting the tool.
