Specification Category |
Feature |
Technical Detail |
|
General |
Brand / Ref No |
EDL-ZX7-160-E1 |
|
|
Range Name |
Yellow Series Tools |
|
|
Size & Spec. |
160A |
|
|
Material |
Plastic + Iron |
|
|
Colour |
Yellow |
|
|
Launch Time |
May-22 |
|
|
HS Code |
8515390000 |
|
Electrical |
Input Voltage (V) |
1~220-240 |
|
|
Frequency (Hz) |
50/60 |
|
|
Max. Output Current (A) |
160 |
|
|
Output Current Range (A) |
20-160 |
|
|
No-Load Voltage (V) |
65±5 |
|
Performance |
Duty Cycle (%) |
120A@40%@25℃ |
|
|
Diameter of Electrode (mm) |
1.6-4.0 |
|
Product Dimensions |
Product Size L x W x H |
34.000 x 17.000 x 24.000 CM |
|
|
Product G.W / N.W |
4875.00 G / 4875.00 G |
|
Protection Class |
IP21S |
|
|
Insulation Class |
F |
|
|
Efficiency (%) |
>85% |
|
|
Recommended Electrode Type |
Rutile (E6013), Basic (E7018) |
|
|
Welding Type |
IGBT Inverter Technology |
|
Enhanced Arc Stability: features Built-in arc-force and Built-in hot arc ignition to ensure easier starting and a more stable arc, improving the quality of the weld.
Anti-Sticking Safety: comes with Built-in anti-sticking, automatically separating the electrode from the workpiece after 3 seconds if the welding rod sticks, preventing damage and simplifying work.
High-Capacity Welding: supports a Max. output current of 160A and can handle electrode diameters ranging from 1.6 to 4.0 mm, suitable for a variety of tasks from light to medium-duty.
Smart Internal Protection: includes Overcurrent protection for automatic work suspension in case of excessive current, safeguarding the machine and the user.
User-Friendly Operation: Built-in indicates internal setting means there is no need for complex external adjustment, allowing for quick setup and focusing on the weld.
