Hikvision DS-1LN6USC0 Pure Copper CAT6 Network Cable | 23AWG 0.55mm Solid Bare Copper | 305m Orange PVC | PoE & Fluke Tested
|
Specification Category |
Specification Detail |
|
Brand |
Hikvision |
|
Model Number |
DS-1LN6USC0 |
|
Conductor Material |
Solid-Bare Copper (99.95%) |
|
Conductor Diameter |
0.55 mm (23 AWG) |
|
Insulation Material |
HDPE |
|
Sheath Material |
PVC (Orange Color) |
|
Cable Length |
305 Meters |
|
DC Resistance |
Less than or equal to 9.38 Ohms per 100m |
|
Operating Temperature |
-20°C to 75°C |
|
PoE Compatibility |
Verified up to 57 V / 1 A |
|
Standard Impedance |
100 Ohms |
|
Item Weight |
12.3 kg |
- 99.95% Solid-Bare Copper: Built with high-purity solid copper conductors for significantly lower electrical resistance and superior signal transmission compared to CCA cables.
- Tested for Extreme Conditions: Successfully passes the Fluke 90m Permanent Link test while operating at a high temperature of 50°C, ensuring reliability in demanding environments.
- Optimized for High-Power PoE: Verified through the Fluke 100m Channel test under a continuous 57V/1A DC power load, making it ideal for advanced PoE devices and CCTV systems.
- High-Visibility Mechanical Sheath: Features a robust Orange PVC jacket with high tensile and compressive strength designed to resist physical damage during complex installations.
- Global Standard Compliance: Fully compliant with ANSI/TIA-568-C.2, IEC61156, and ISO/IEC11801 standards, guaranteeing compatibility with all professional networking hardware.
