Hikvision Unmanaged Gigabit Switch Series | 4 / 8 / 16 / 24 Port Options | 1000Mbps Full Speed | Metal & ABS Shell | Plug & Play
|
Attributes |
DS-3E0505D-E |
DS-3E0508D-E |
DS-3E0516-E |
DS-3E0524-E |
|
Port Count |
4 x Gigabit RJ45 |
8 x Gigabit RJ45 |
16 x Gigabit RJ45 |
24 x Gigabit RJ45 |
|
Switching Capacity |
10 Gbps |
16 Gbps |
32 Gbps |
48 Gbps |
|
Packet Forwarding Rate |
7.44 Mpps |
11.9 Mpps |
23.81 Mpps |
35.72 Mpps |
|
MAC Address Table |
2 K |
4 K |
8 K |
8 K |
|
Shell Material |
ABS Plastic |
ABS Plastic |
Metal |
Metal |
|
Cooling |
Fanless |
Fanless |
Fanless |
Fanless |
|
Surge Protection |
Standard |
Standard |
Standard |
6 KV |
|
Power Supply |
5V DC |
5V DC |
220V AC |
220V AC |
|
Installation Mode |
Desktop / Wall |
Desktop / Wall |
Rack / Desktop |
Rack / Desktop |
|
Dimensions (mm) |
92.8 x 65.8 x 22.8 |
124 x 59 x 23 |
257 x 44.5 x 175 |
335 x 44.5 x 175 |
- Full Gigabit Connectivity: Equipped with high-speed 10/100/1000 Mbps ports that provide maximum bandwidth for data-intensive applications and high-resolution video streaming.
- Non-Blocking Architecture: Utilizes wire-speed forwarding to ensure that all ports can handle full Gigabit speeds simultaneously without any internal data bottlenecks.
- Rugged & Silent Design: The 16 and 24-port models feature a high-strength metal shell and a fanless thermal design, ensuring silent operation and long-term durability.
- Intelligent Data Management: Supports MAC address auto-learning, auto-aging, and store-and-forward switching to maintain high data integrity and efficient routing.
- Instant Deployment: A true plug-and-play solution that requires no configuration, featuring Auto MDI/MDI-X to automatically detect and adapt to any Ethernet cable type.
