Specification Category |
Feature |
Technical Detail |
|
General |
Model / Item Code |
CS-H90-R100-8H44WKFL |
|
|
IP Grade |
Weatherproof IP65 |
|
|
Operating Temperature |
Minus 30 degrees C to 50 degrees C |
|
Camera/Video |
Max Resolution |
2560 x 1440 (2K+) |
|
|
Dual Lens Focal Length |
2.8mm and 6mm |
|
|
IR Night Vision Distance |
30 meters / 98 feet |
|
|
Color Night Vision Distance |
Up to 40 meters / 131 feet |
|
|
Bottom Lens PT Angle |
Pan: 324 degrees, Tilt: 90 degrees |
|
|
Video Compression |
H.265 / H.264 |
|
Connectivity |
Wi-Fi Standard |
IEEE802.11b/g/n (2.4 GHz) |
|
|
Wired Network |
RJ45 x 1 (10M / 100M Adaptive Ethernet Port) |
|
|
Local Storage |
Supports MicroSD Card (Max. 512 GB) |
|
|
Power Consumption |
Max. 18 Watts |
|
Audio |
Two-way Talk |
|
|
Smart Alarm |
Human and Vehicle Detection |
|
|
Certifications |
CE, UL, WEEE, RoHS, REACH |
|
|
WDR |
Digital WDR |
|
Dual-Lens System with 2K+ Resolution: Features two distinct lenses (2.8mm and 6mm) offering wide and detailed views simultaneously, recording video at a high maximum resolution of 2560 by 1440 (2K+ pixels).
Extended Color Night Vision: Achieves up to 40 meters (131 feet) of color night vision when both lenses are directed toward the same area, greatly enhancing security and detail capture after dark.
Comprehensive Coverage: The dual-lens setup provides both a manually adjustable wide-angle view and a second Pan-Tilt lens (324 degrees horizontal, 90 degrees vertical), ensuring massive area coverage and eliminating blind spots.
Advanced AI Detection: Incorporates AI-powered detection for both human shapes and vehicle shapes, providing highly accurate alerts and supporting Auto Tracking to follow moving subjects.
Extreme Weather Performance: Built with a weatherproof design rated IP65 (plus verified for 2-hour rainstorm resistance), guaranteeing reliable operation in harsh outdoor conditions from minus 30 degrees Celsius to 50 degrees Celsius.
