Specification Category |
Feature |
Technical Detail |
|
General |
Model / Item Code |
CS-H8-R100-1J5WKFL |
|
|
IP Grade |
Weatherproof Design |
|
|
Operating Temperature |
Minus 30 degrees C to 50 degrees C |
|
Camera/Video |
Max Resolution |
2880 x 1620 Pixels (3K) |
|
|
Lens Focal Length |
4mm and 6mm options |
|
|
PT Angle |
Pan: 340 degrees, Tilt: 80 degrees |
|
|
Night Vision Distance |
Up to 30 meters / 98 feet |
|
|
Video Compression |
H.265 / H.264 |
|
Connectivity |
Wi-Fi Standard |
IEEE802.11b/g/n (2.4 GHz) |
|
|
Wired Network |
RJ45 x 1 (10M / 100M Adaptive Ethernet Port) |
|
|
Local Storage |
Supports MicroSD Card (Up to 512 GB) |
|
|
Power Supply |
DC 12V / 1A |
|
|
Power Consumption |
Max. 6 Watts |
|
Smart Alarm |
AI Human/Vehicle/Waving Hand |
|
|
Max Frame Rate |
Maximum 30 frames per second |
|
|
Certifications |
UL, FCC, CE, WEEE, RoHS, UKCA |
|
|
Net Weight |
592 grams |
|
Ultra HD 3K Resolution: Captures exceptionally clear video with a maximum resolution of 2880 by 1620 pixels, referred to as Quad HD Plus or 3K, providing sharp detail over a wide area.
Smart 360-Degree Tracking: Offers mechanical pan and tilt with 340-degree pan and 80-degree tilt, enabling complete area monitoring, complemented by Auto Tracking for following moving subjects.
Advanced AI Interaction: Features cutting-edge AI Powered Human and Vehicle Detection, plus Waving-Hand Recognition and Control, allowing you to start video calls or activate features with a simple gesture.
Reliable Night Vision and Two-Way Audio: Provides clear infrared night vision up to 30 meters (98 feet) and supports seamless Two-way Talk, enabling remote communication and deterrence.
All-Weather Durability and Storage: Built with a Weatherproof Design to operate reliably from minus 30 degrees Celsius to 50 degrees Celsius. Supports local storage via a Micro SD card up to 512 Gigabytes.
